Size Matters: This is a 16" fan. Unlike other electric fans, the size indicates the size of the blade not the assembly.

Reversible push/pull blades.
High quality, long life motors.
Thin, aerodynamic profile.
Full fingerguard shroud.
Available in 16" high performance.
Super Quiet hi-flow S-Blade Design.
.
24 Volt HP Radiator Fan (16")

This 24 volt High-Performance 16" Radiator Fan is designed for military or ex-military vehicles with 24 volt electrical systems (Uni-Mog, Pinzgauer, HumVee, Land Rover, Volvo, etc.).

Electric fans are ideal for O.E. replacement, supplemental or add-on cooling needs. As a primary cooling source electric fans provide economical replacement for failed OE parts, with a 5-10% increase in horsepower and fuel mileage when replacing belt-driven fan assemblies. As an add-on cooling source electric fans provide increased air conditioning performance due to constant airflow across the condenser, with additional cooling in heavy traffic or while towing, or driving off-road.

Is your vehicle ex-military with a 24 volt system? Double battery 24 volt systems are superior in many ways to 12 volt models. Don't even think about converting to 12 volt, and it is not recommended to draw power from one battery only.

.
U.S. SHIPMENTS (CONTINENTAL U.S. ONLY)
(16") 24 Volt HP Radiator Fan
Shipping
. $149.95
$20.00
*
.

Total . $169.95 .
.
.
* Includes sales tax where applied .

.
.
. .
.
. .
.
. .


.
24 volt System Info

24 volt electrical systems are found mostly in military vehicles such as Land Rovers, Pinzgauers, HummVees, and Unimogs. The system is made up of two standard 12 volt batteries. This differs from a dual battery system in a 12 volt truck, however. Instead of being connected in parallel, the two batteries are hooked up in series.

Parallel: Positives connected, and both negatives go to ground.

Series: Ground connected to negative terminal, positive connected to second negative, and second positive connected to all units.

Never run 12 volt accessories from one battery, especially a 12 volt unit that draws alot of power (winch, etc.). The danger is that power will be drawn from only one battery and the system will become unbalanced.

Some Do's & Dont's with 24 volt systems:
Do not draw power from only one battery for ANYTHING.
Swap around the batteries several times in the season.
Always charge both batteries fully.
Both batteries must be of the same type.

High efficiency vs. low efficiency converters:
Both high and low efficiency converters are available. Low efficiency converters are cheaper, larger and dissipate extra voltage by heat conversion. Units have large heat fins, and become quite hot. High efficiency converters are superior, run cooler, but are more expensive.
. .

.
